JBL HDI-1600 Bookshelf Loudspeaker

A two-way with rear-firing port, 6.5" woofer and 1" horn-loaded tweeter

Designed and engineered in JBL’s world-famous acoustic engineering facility in Northridge, California, the HDI-1600 delivers exceptional performance from a compact enclosure. This bookshelf loudspeaker features a 2-way design with patented High-Definition Imaging (HDI™) waveguide technology, the patented 2410H-2 1-inch compression driver, and a 6.5-inch Advanced Aluminum Matrix cone woofer for powerful dynamics and incredibly accurate sound reproduction.

The HDI-1600 enclosure is heavily braced to provide a solid acoustic foundation, and incorporates a bass reflex design with dual rear-firing, computer-optimized flared ports. The sophisticated curved cabinet features a modern design finished in a choice of automotive-grade painted High Gloss Black, or furniture-grade satin Walnut or Gray Oak wood veneers. A black cloth, magnetically attached grille completes the luxurious appearance.

Features

• Patented HDI™ (High-Definition Imaging) waveguide technology
• Patented 2410H-2 high-frequency compression driver
• 6.5-inch (165 mm) cast frame, Advanced Aluminum Matrix cone woofer with 1.5-inch voice coil
• Contemporary design with premium finishes including high-gloss Black, satin Gray Oak wood veneer, and satin Walnut wood veneer

Specifications

Enclosure: Bass-reflex design with rear-firing port

Drivers
HF: 1" (25 mm) Teonex compression driver
LF: 6.5" (165 mm) black Advanced Aluminum Matrix cone, cast frame woofer

Crossover Frequency: 1,900 Hz

Sensitivity: 85 dB

Nominal Impedance: 4 Ohm

Frequency Response (-6 dB): 40 Hz – 30 kHz

Dimensions (HWD): 14.57 x 9.06 x 11.375” (370.0 x 230 x 288.9 mm)

Weight: 21.96 lb. (9.96 kg)
