Lumin X1 Network Music Player

Streaming's New Cutting Edge

Never content, Lumin has been constantly been evaluating its streamers to see if there was any possible way to beat them. It's taken years, but finally Lumin is ready to reveal streaming's new cutting edge.

Re-engineered throughout

LUMIN X1 makes improvements in every possible location:

  • New processor delivers native DSD512 & PCM768 playback
  • Dual Mono design throughout maximises channel separation
  • Dual ES9038Pro SABRE DACs featuring 140dB dynamic range
  • Fully balanced layout with high-quality components
  • Femto Clock System with precision FPGA distribution
  • Output connectors coupled with dual Lundahl LL7401 output transformers
  • New Output Buffer design
  • Dual Mono dual stage linear regulator
  • Optical Network provides complete isolation from network digital noise
  • USB Digital Audio Output supports Native DSD512

Entirely new power supply

  • New solid billet CNC casing design
  • Separate digital & analogue circuitry
  • Low-noise linear regulator
  • New 9-pin output connector
  • Available as an upgrade for existing S1 / A1 / T1 customers

Specification

DSD support: Up to DSD512 22.6mhz, 1-bit
PCM support: Up to 768khz, 16–32-bit, stereo
Analog output stage: Dual ESS SABRE32 ES9038PRO DAC chips
Upsampling rates & bit depths: DSD128 upsampling option for all files
PCM 384kHz upsampling option for all files

Digital output stage

USB: Native DSD512 support,PCM 44.1–768kHz, 16–32-bit, stereo
BNC S/PDIF: PCM 44.1khz–192khz, 16–24-bit; DSD (DoP, DSD over PCM) 2.8mhz, 1-bit
Optical network: Industry-standard SFP,  1000base-T Eigabit Ethernet. Adapter may be needed for your particular switch/cables. Use simultaneously with RJ45

Dimensions

X1: 350mm (w), 345mm (d), 60mm (h), 8kg

PSU: 106mm (w), 334mm (d), 60mm (h), 4kg
